Hidraulična zupčasta pumpa GHP2
GHP2A jednostruke pumpe sa aluminijumskim kućištem visokih performansi sa prirubnicom od livenog gvožđa i poklopcem. Ova serija pumpi je upotrebljiva u sistemima za teške uslove rada. Dostupan u jednoj rotaciji i reverzibilan.
|
Ime |
PA-GHP2A serija Hidraulična zupčasta pumpa |
|
Serije |
Serija 2 |
|
Veličine |
4.5 6.4 7 8.3 9.6 11.5 14.1 16 17.9 21.1 23. 7 25.5 28.2 35.2cc/rev |
|
Nominalni pritisak |
250 bara |
|
Maksimalni pritisak |
280 bara |
|
Način rada |
Eksterne zupčaste pumpe |
|
TYPE |
Displacement |
FLOW at |
MAX PRESSURE |
MAX SPEED |
||
|
P1 |
P2 |
P3 |
||||
|
GHP2A-D(S)-6 |
4.5 |
6.4 |
280 |
295 |
310 |
4000 |
|
GHP2A-D(S)-9 |
6.4 |
9.1 |
280 |
295 |
310 |
4000 |
|
GHP2A-D(S)-10 |
7 |
10 |
280 |
295 |
310 |
4000 |
|
GHP2A-D(S)-12 |
8.3 |
11.8 |
280 |
295 |
310 |
4000 |
|
GHP2A-D(S)-13 |
9.6 |
13.7 |
280 |
295 |
310 |
4000 |
|
GHP2A-D(S)-16 |
11.5 |
16.4 |
280 |
295 |
310 |
4000 |
|
GHP2A-D(S)-20 |
14.1 |
20.1 |
260 |
275 |
290 |
3200 |
|
GHP2A-D(S)-22 |
16 |
22.8 |
260 |
275 |
290 |
2800 |
|
GHP2A-D(S)-25 |
17.9 |
25.5 |
260 |
275 |
290 |
2500 |
|
GHP2A-D(S)-30 |
21.1 |
30.1 |
230 |
245 |
260 |
2200 |
|
GHP2A-D(S)-34 |
23.7 |
33.7 |
230 |
245 |
260 |
2000 |
|
GHP2A-D(S)-37 |
25.5 |
36.4 |
210 |
225 |
240 |
1800 |
|
GHP2A-D(S)-40 |
28.2 |
40.1 |
200 |
215 |
230 |
1800 |
|
GHP2A-D(S)-50 |
35.2 |
50.2 |
160 |
175 |
190 |
1800 |
|
GHP2-D(S)-6 |
4.5 |
6.4 |
280 |
295 |
310 |
4000 |
|
GHP2-D(S)-9 |
6.4 |
9.1 |
280 |
295 |
310 |
4000 |
|
GHP2-D(S)-10 |
7 |
10 |
280 |
295 |
310 |
4000 |
|
GHP2-D(S)-12 |
8.3 |
11.8 |
280 |
295 |
310 |
4000 |
|
GHP2-D(S)-13 |
9.6 |
13.7 |
280 |
295 |
310 |
4000 |
|
GHP2-D(S)-16 |
11.5 |
16.4 |
280 |
295 |
310 |
4000 |
|
GHP2-D(S)-20 |
14.1 |
20.1 |
260 |
275 |
290 |
3200 |
|
GHP2-D(S)-22 |
16 |
22.8 |
260 |
275 |
290 |
2800 |
|
GHP2-D(S)-25 |
17.9 |
25.5 |
260 |
275 |
290 |
2500 |
|
GHP2-D(S)-30 |
21.1 |
30.1 |
230 |
245 |
260 |
2200 |
|
GHP2-D(S)-34 |
23.7 |
33.7 |
230 |
245 |
260 |
2000 |
|
GHP2-D(S)-37 |
25.5 |
36.4 |
210 |
225 |
240 |
1800 |
|
GHP2-D(S)-40 |
28.2 |
40.1 |
200 |
215 |
230 |
1800 |
|
GHP2-D(S)-50 |
35.2 |
50.2 |
160 |
175 |
190 |
1800 |
